Overview
Quick Details
- Applicable Industries:
- Printing Shops, textile machinery
- Type:
- Timing
- Material:
- Steel
- Place of Origin:
- Xiamen, China
- Brand Name:
- Pinmo
- Surface treatment:
- Blackening
- Bore Type:
- Keyway Hole
- Weight:
- 471 g
- Teeth Number:
- 14 Teeth
- Total Diameter:
- 63 mm
- Total Height:
- 49 mm
- Edge Thread Hole Diameter:
- 2-M8
- Flange Thickness:
- 2-2 mm
- Teeth Width:
- 14-4.2 mm
- Center Hole Outer Diameter:
- 2-48 mm
Product Description
| Material | Copper Powder ;Iron Powder |
| Certificate | ISO9001:2008 |
| Tolerance | ± 0.02-0.1mm, |
| Density Range | 6-7.2/cm3(Fe) |
| Surface Treatment | Blacken,Dacromet Plated ,Polishing,Sand Blasting,Electroplating,Oil immersion |
| Heat Treatment | Ordinary Quenching,Carburizing, Ritriding, High Frequency Quenching |
| Application | Sport Equipment,Home Appliances,Transmission Parts,Vehicle,etc |
| Performance | High Precision,High Wear Resistance,Low Noise,Smooth And Steady,Cheap |
| Processing Technic | Powder Metallurgy Sinter |
| Process | Mixing-Mechanical Forming-Hydraulic Molding-Sinter-Detection Strength And Hardness-Auxiliary Machining And Surface Treatment -Packing And Shipping |
| flange outer diameter | 63 mm |
| tip circle diameter | 55.3 mm |
| root circle diameter | 50.1 mm |
| inner diameter | 32 mm |
| inner diameter 1 | 29.3 mm |
| flange thickness | 2-2 mm |
| total height | 49 mm |
| height | 45 mm |
| center hole outer diameter | 2-ø48 mm |
| teeth number | 14 teeth |
| teeth width | 14-4.2 mm |
| chamfer | 1*45° |
| teeth shape | T shape teeth |
| surpace treatment | blackening |
| Weight | 40 g |
| Material | iron,steel |
